Laserworld BeamBar 10G MK3

The BeamBar 10G MK3 is a laser bar composed of 10 independent apertures, each equipped with a 90 mW / 520 nm green laser module, designed to create spectacular fan, chase, and parallel beam effects. Each source can be controlled individually via 13 DMX channels, allowing for high precision and seamless integration into professional lighting setups.

The lasers operate using analog modulation, which ensures smoother output and more accurate light intensity control. Beam alignment is simplified thanks to the front-accessible 4-point adjustment system, which eliminates the need to open the case and speeds up setup.

The BeamBar 10G MK3 can operate in DMX, stand-alone, sound-to-light and Master/Slave modes, making it versatile for both fixed installations and live events. Its solid construction and high-quality optical profile make it an effective solution for creating linear and dynamic effects wherever it is used.

User benefits

• Analog modulation for smooth transitions
• 13-channel DMX control
• Quick alignment via a front-mounted 4-point system
• Various operating modes
• Immediate integration into professional lighting setups

Areas of use

• Stages and live productions
• Concerts and live performances
• Clubs and discos
• TV programs
• Shows and scenic productions

Technical characteristics

• Guaranteed power: 900 mW
• Green output: 10 × 90 mW / 520 nm
• Laser source: diode
• Laser Class: 3B
• Beam specifications: approx. 3.0 mm / 0.8 mrad
• Modulation: analog

• Operation modes: DMX, stand‑alone, sound‑to‑light, Master/Slave
• DMX channels: 13
• Individual beam alignment: 4‑point front‑access system

• Power supply: 100 – 250 V_AC 50/60 Hz
• Power consumption: 50 W

• Dimensions: 100 x 16 x 8 cm
• Weight: 9 kg
• What's in the box:
  • BeamBar 10G MK3
  • Interlock connector
  • Manual
  • Key
