SKU: FT-20X

ean13: 4710586554465

mpn: FT-20X

Antari

Antari FT-20XE

600 W battery operated fire training fogger, red painting, FLM-05P fog liquid and flight case included
star_border star_border star_border star_border star_border
(0)

624.50 €

(VAT excluded)

Pay in 4 interest-free payments of 156.13 € with Discover More

Unfortunately, the quantity you have selected exceeds the amount available in stock.
Unfortunately, the quantity you have selected exceeds the amount available in stock. No problem! We will go ahead and send you the available quantity. We will then send you the reminder approximately within ten days.
624.50 €
Condition

Not available.

delivery is not available for this product.

Free Shipping for order equal or above € 199 are limited for delivery within Europe

Variants of this product

Antari - MB-1E

381.00 €

Battery operated mobile fogger, dark painting, battery operated, charger, FLM-05S fog liquid and flight case
Le Maitre - RESCUE 300

2,171.00 €

High-powered smoke generator specifically for the Emergency Services
Antari - Z-3000IIIE

524.50 €

2500 W fog machine, water based compatible fluids, LCD display, fluid level detection
Antari - Z-1200IIIE

312.50 €

1200 W fog machine, water based compatible fluids, DMX control, LCD display, with Unicord (you can clean the heater if it clogged)
Antari - IP-1600E

670.50 €

1500 W waterproof fog machine, IP64, high-pressure pump, DMX and wireless control, liquid level detection, Dual Thermal Cut-Off (TCO) technology
Le Maitre - GFORCE 1

868.00 €

Continuous flow, water-based entry level smoke machine, max. output 19,000 m3/hour

EN Instruction manual (1.46MB)

NO DESC

Documentation

See it in action

Video Youtube
Close the video

Product details

The FT-20XE is a portable battery-powered smoke generator designed to provide long-term operation with massive smoke production.

This device can be powered by either a 12 VDC battery or a switching power supply (optional), allowing operation on AC between 100 and 240 VAC. It requires no warm-up time, allowing constant smoke to be generated immediately at the push of a button. In battery mode, the device can produce approximately 11 minutes of continuous smoke, while in mains mode, smoke production can continue without interruption as long as there is liquid in the tank.

The device is equipped with a rotary knob to adjust the smoke volume and offers optional DMX control. The liquid tank has a capacity of 0.4 liters and the liquid consumption is 16 ml per minute. The device is compatible with Antari FLM-05P smoke liquid and can be controlled manually, via DMX 512 or with an optional remote control.

Benefits for users

  • Possibility to use the device anywhere without the need for power, thanks to the internal battery
  • Virtually zero preheating time
  • Possibility to adjust the volume of smoke emitted
  • Long duration of use (liquid consumption of 16 mL/min)
  • Easy to transport and handle

Areas of use

  • Fire training
  • Theatre and film productions
  • Concerts, festivals and other live events
  • Photography and videography
  • Artistic performances

Technical characteristics

  • Rated voltage: 12 VDC (battery), 100 - 240 VAC 50/60 Hz (battery charger)
  • Rated power: 600 W
  • Warm-up time: 1 s (approx.)
  • Fluid consumption: 16 ml/min
  • Fluid tank capacity: 0.4 L
  • Ambient temp range: 0 to 40 °C
  • Control: manual, DMX 512, wireless (optional), cable remote (optional)
  • DMX channels: 1
  • Connection: XLR 3-pin (DMX)
  • Compatible fluid: Antari FLM-05P fog fluid
  • Optional accessories: WTR-20 wireless remote, Z-3 cable remote, FT-20XS power base
  • Dimension: 29.3 x 10.8 x 23.8 cm
  • Weight: 8.5 kg
  • What's in the box:
    • FT-20X-B battery
    • FT-20X-BCL charger
    • FLM-05P fog fluid 500ML
    • FFT-20 flight case
