SHOWVEN PyroSlave

Sistema de ignición de 16 canales especialmente diseñado para técnicos y profesionales de efectos especiales para adaptarse a aplicaciones extremas al aire libre.

Equipado con una robusta carcasa de aluminio, teclas táctiles, terminales de conexión de metal, este equipo puede usarse tanto cableado como inalámbricamente. El modo inalámbrico con antenas de doble banda comunica simultáneamente, evitando interferencia de señal en una sola banda de frecuencia. La tecnología PBUS de 2 cables usada en la comunicación cableada con la máquina de efectos puede realizar el suministro de energía durante la comunicación.

Technical characteristics

• Robust aluminum housing and metal connection terminals, waterproof and dustproof as well as prevent the impact of sparks drop from fireworks
• Can be operated both wired and wirelessly
• Wired mode with 2-wire PBUS technology can realize power supply while communicating, ensure continuous working
• Wireless mode with dual band antennas communicate simultaneously, preventing signal interference on a single frequency band
• Wireless mode with 4 wireless channel, 65536 ID, ensure the safety firing. Only when FXcommander and Slave with exactly the same wireless channel and ID before they can communicate
• Firing precision: 100 firings/s
• Bridge function to avoid signal obstacles behind big stage
• 2 x M10 hole convenient for truss installation
• Output: 16
• Trigger indicate LCD display and record
• Address 256 (00 to FF)
• Control dual-band wireless, 2-wire PBUS (communication + charging)
• Wireless range: 600 m
• Wired range: 2000 m
• Voltage: 24 V
• Current: 5 A
• Activation period: 500 ms
• Resistance test: yes
• Battery: 4 x 18650 cell, 4.2 V, 2500 mAh per piece
• Operation time: 60 h, sleep mode 2 weeks, wired communication non-stop
• Charging control: a PyroAdaptor support 20 PyroSlave X16 units
• Charging time: appr. 6 h
• Waterproof level: IP65
• Minimum firing interval: 10 m
• Dimension: 335 x 165 x 85 mm
• Net weight: 3 kg
